| Display Type | Single 0.67" DLP® Technology by Texas Instruments |
| Brightness (Typical) | 7,000 ANSI Lumens |
| Native Resolution | WUXGA (1920 x 1200), 16:10 Format |
| Contrast Ratio | 20,000:1 (Full On/Off) |
| Laser Life and Type | 20,000 + hours (Laser Phosphor Light Engine) |
| Throw Ratio | 1.15 to 1.9:1 (Distance/Width) |
| Image Size (Diagonal) | 37 – 202" |
| Projection Distance | 4.9' to 16.4' (1.5 to 5m) |
| Projection Lens | F# 2.45 – 3.13, f=17.23 – 27.9mm |
| Zoom Ratio | 1.65:1 Manual Zoom/Focus |
| Aspect Ratio | 16:10 Format |
| Offset | 115% - 130% |
| Keystone Correction | ± 30° Vertical, Horizontal ± 30° |
| Color Spectrum | 1.07 Billion |
| Horizontal Scan Rate | 15, 31 ~ 102KHz |
| Vertical Scan Rate | 24 ~ 30Hz, 47 ~ 120Hz |
| 3D Functionality | Full 3D (Via DLP® Link, Blu-ray and Broadcast 3D) |
| Speaker | 5W(x2), 10W total |
| Lens Shift Range | Vertical: 12%, Horizontal: +/- 5% |
| Remote Control | Fully Featured IR Remote |
| Projection Method | Table Top or Ceiling Mount (Front or Rear) |
| Uniformity | 85% |
| I/O Connection Ports | HDMI (x3), HDMI 1.4b/MHL, Microphone-In (Mini-Jack), RJ45 (LAN), HDBaseT, RS-232c, VGA-In/Out, 3D Sync, Composite, Power-Out (5V/1.5A) USB Type A, Audio-In, RCA L/R, Audio-Out (Mini Jack), Service Only (USB Type B) |
| Security | Kensington® Lock Port, Security Bar |
| Weight | 23.6lbs (10.7kg) |
| Dimensions (W x D x H) | 14.2" x 17.8" x 6.5" (360 x 451.6 x 166mm) With Feet; 14.2" x 17.8" x 6.0" (360 x 451.5 x 151mm) Without Feet |
| Noise Level | 38dB / 33dB (Normal / Eco) |
| Power | Supply: AC 100-240V, 50/60Hz; Consumption: 530W/380W (Normal/Eco), < 0.5W (Standby Mode), < 2W (LAN Standby) |
| Operating Temperature | 41 to 104°F (5 to 40°C) |
| Standard Accessories | AC Power Cord, VGA Cable, Remote Control, Batteries for Remote, User Manual (CD), Warranty Card |
Laser phosphor light source: Solid state laser phosphor light source, lamp-less, mercury-free and almost maintenance-free with up to 20,000 hours of operating time
Brightness and resolution: 7,000 lumens with native WUXGA (1920 x 1200), DLP DarkChip3 and BrilliantColor technologies
Lens and installation: 1.65x manual zoom and focus, horizontal and vertical lens shift, keystone and 4-corner adjustment
HDBaseT and MHL: HDBaseT interface for HD video and digital audio over standard CAT5e/6 cable, and MHL device compatibility
360° and portrait: 360° operation and projection design, with portrait mode projection
Sealed engine: Airtight sealed engine and filter-less design for improved performance against dust and fibres
Network control: Network ready via RJ45, with Crestron RoomView integration for monitoring and management
Supplied through the authorised manufacturer channel with full warranty. Installation, network configuration and user handover are included.
Warranty as per Vivitek India: 2 years on the projector. Warranty terms for the laser light source are confirmed in the quotation.
