| Display Type | Backlit D-LED (IPS Panel) |
| Panel Size | 92" |
| Native Resolution | 5120 x 2160 |
| Brightness | ≥450nits Typical |
| Contrast Ratio | 5,000:1 |
| Viewing Angle (H/V) | 178°/178° |
| Aspect Ratio | 21:09 |
| Bonding Technology | Zero Bonding |
| Refresh Rate | 60Hz |
| Display Color | 1.07 Billion (10-bit) |
| Installation Orientation | Landscape |
| Working Life | 50,000 Hours (Typical) |
| Touch Technology | Infrared Touch |
| Touch Points | ≥40 Points |
| Touch Accuracy | ±1mm (Over 90% Area) |
| Touch Response | < 5ms (Typ.) |
| Touch Resolution | 32,768 x 32,768 |
| Surface Protection | Anti-Glare Thick Toughened Glass (9H) |
| Touch Tools | Finger, Stylus, Glove, Opaque Objects |
| System Version | Android v13.0 |
| CPU | Octa-Core ARM Cortex |
| GPU | Mali G52 |
| RAM | 8GB |
| Internal Storage | 128GB |
| Display Input | HDMI x3, DP x1, VGA x1 |
| Audio Input | VGA Audio (x1), Mic In (x1) |
| Display Output | HDMI-Out x1 |
| Audio Output | Line-Out (x1), SPDIF-Out (x1) |
| Internet | LAN (RJ45) (x2) |
| Control | RS232-In (x1) |
| Wi-Fi | Wi-Fi 6 IEEE802.11ax (2.4GHz/5GHz) |
| Bluetooth | BT 5.2 |
| I/R Receiver | Front (x1) |
| USB-A Front | USB 3.0 (x1) |
| USB-A Side | USB 3.0 (x1), USB 2.0 (x1) |
| USB-B Front | USB Type-B (Touch) |
| USB-B Side | USB Type-B (Touch) |
| USB-C | USB-C (x1) |
| Card Slot | Micro SD |
| Expansion | Standard Intel 80pin OPS (Optional) |
| Speakers | 20W (x2) Stereo |
| Microphone | 8-Microphone Array (8M Pickup) |
| Camera | 48MP |
| Working Temperature | 0°C – 40°C |
| Working Humidity | 10% – 80% |
| Power Supply | AC 100–240V, 50/60Hz |
| Power Consumption | ≤450W (Typ.) |
| Standby Mode | ≤0.5W |
| VESA Mounting | 800 x 400mm |
| Dimensions (L × H × D) | 2218.6 × 1034.9 × 105.8 mm |
| Standard Accessories | AC Power Cord, Stylus (x2), Remote Control, Wall Mount Kit, HDMI Cable, Touch Cable, Documentation Kit, Antenna |
Ultra-wide 5K display: 5120 x 2160 native resolution with a 21:9 aspect ratio for multitasking and immersive video conferencing
Delta DConnect+: Cable-free screen sharing across Windows, macOS, Android and iOS
Hybrid workspace: Supports the Microsoft Teams Front Row layout and advanced Zoom Room setups
AI-driven camera: Built-in auto-framing keeps participants centred
Audio: Dual 40-watt speakers
Zero bonding: Zero-bonded IPS panel under 9H anti-glare toughened glass
Supplied through the authorised manufacturer channel with full warranty. Installation, network configuration and user handover are included.
Supplied through the authorised Delta channel with manufacturer warranty support. Warranty terms are confirmed in the quotation.
